Autoclave Vertical High Pressure

autoclave-vertical-high-pressure-supplier-manufacutrer-in-delhi-india



Construction : Triple walled construction, all the three walls are made of thick high grade stainless steel sheet. The lid is made of stainless steel sheet. The unit is fitted with radial locking system with paddle lifting device, made of MS chrome plated. Provided with built- in safety valve, pressure gauge, pressure release valve and water level indicator. The pressure is adjustable from 5 psi to 20 psi with automatic pressure control switch, which controls the pressure with an accuracy of +/- 1 psi. Supplied complete with stainless steel basket, chord and plug.

Mode of Heating : Electrically heated by special flange type/immersion type heaters, to work on 220 volts single phase 50 cycles.

Working Pressure : The pressure inside the chamber is variable from 5 psi. to 20 psi. But the normal recommended pressure for sterilization process is 1.2 kgf/cm sq.g ( 15 psi - 17 psi ).

Working Temperature : 121° C

Hydrotest Pressure : 2.5 kgf/cm sq.g ( 35 psi )


Sizes

Sizes in MM
450 x 250 mm 500 x 300 mm 400 x 600mm 550 x 300 mm 600 x 450 mm
750 x 550 mm
